The HZS35 is our bestselling mid-range stationary batching plant — upgraded JS750 twin-shaft mixer with PLD1200 batching machine. Ideal for commercial concrete supply companies, medium-scale construction projects, and precast factories requiring consistent high-quality output.
Upgraded twin-shaft forced mixer with 750L nominal capacity. Handles a wider range of mix designs including high-slump and low-slump concretes.
PLD1200 batching machine with 3 aggregate bins, each 3.5 m³ — reducing loader feeding frequency and improving batching rhythm.
Electronic load-cell weighing with automatic compensation. 3-bin cumulative weighing ensures consistent aggregate proportioning.
PLC-based automatic control with touchscreen interface. Stores 100+ mix formulas, prints batch reports, and logs production data.
Enclosed mixer housing and rubber-lined aggregate bins reduce noise and dust — compliant with urban construction regulations.
Modular bolt-together design packs into 2 × 40ft containers. Factory pre-assembled sub-components for rapid on-site installation.
| Model | HZS35 |
| Theoretical Productivity | 35 m³/h |
| Mixer Model | JS750 Twin-Shaft |
| Mixer Power | 30 kW |
| Mixing Cycle | 72 s |
| Mixer Nominal Capacity | 750 L |
| Max Aggregate Size | Φ80 mm |
| Batching Machine | PLD1200 (3-bin, cumulative weighing) |
| Aggregate Bin Capacity | 3 × 3.5 m³ |
| Aggregate Types | 3 |
| Belt Conveyor Capacity | 120 t/h |
| Screw Conveyor | LSY219, capacity 40 t/h, 11 kW |
| Cement Silo | 80T (panel-type, electric dust removal, safety valve) |
| Aggregate Weighing | 0–3500 kg, accuracy ±2% |
| Cement Weighing | 0–2000 kg, accuracy ±1% |
| Water Weighing | 0–800 kg, accuracy ±1% |
| Additive Weighing | 0–150 kg, accuracy ±1% |
| Discharge Height | 3.8 m |
| Installed Power | 85 kW |
| Control System | PLC automatic, PC with printing (CN/EN) |
| Air Compressor | 7.5 kW |
| Compliance | GB/T 10171-2005 |
